CRC-205C 206 Diesel Common Rail Injector Test Bench

///Price before tax! --》》》Contact us to get wholesale price for large quantity!
Guaranteed Safe Checkout

GBT-205C is the latest special equipment for testing the performance of high-pressure common rail injectors launched by our company. It can test common rail injectors produced by BOSCH, SIEMENS, DELPHI, and DENSO. The equipment fully simulates the injection system principle of the high-pressure common rail engine, and the main drive adopts servo control technology. The oil pump speed, fuel injection pulse width and rail pressure of the test bench are all controlled by the industrial computer to collect data in real time, the oil flow rate is displayed, and the debugging data is automatically compared. 10.4〃 LCD touch screen display, built-in more than 1000 kinds of debugging data, which can be queried and printed (optional). The test bench adopts drive signal modulation, high control precision, reliable and stable work. This is a testing equipment powered by AC 220V, and it is specially developed for customers who do not have 380V three-phase AC.

Functions

(1) Testing injector brands: BOSCH, DENSO, DELPHI, SIEMENS;

(2) Measure the tightness of the high-pressure common rail injector;

(3) Measuring the full-load fuel volume of the high-pressure common rail injector;

(4) Measure the oil return volume of the high-pressure common rail injector;

(5) Measure the start-up oil volume of the high-pressure common rail injector;

(6) Measure the pre-injection of the high-pressure common rail injector;

(7) Measure the medium-speed oil volume of the high-pressure common rail injector;

(8) It can query, store and print (optional) data.



 Features

(1) The drive of the main engine adopts servo control;

(2) Industrial computer real-time control.

(3) Oil quantity measurement is measured by a flow sensor and displayed on a 10.4″ touch screen;

(4) Real-time measurement of rail pressure, rail pressure closed-loop control, and high-pressure protection function;

(5) It can query, store and print (optional) data;

(6) The pulse width of the fuel injector driving signal is adjustable;

(7) It has a short-circuit protection function;

(8) Using plexiglass protective door, the operation is more intuitive and safer;

(9) Use AC 220V single-phase power supply.





Weight180 kg
Dimensions70 × 81 × 82 cm
Brand

GBT
